USB to RS-485 Adapter

USB to RS-485 Adapter

UTS-485XS

USB to RS-485 adapter provides an extra serial com port via USB connection and can be configured to work with RS-485 peripherals such as POS and industrial controlled devices. The USB adapter supports an easy serial port expansion and requires no IRQ, DMA, or I/O port resources. The USB adapter features a full set of RS-485 data and control signals on its DB-9. It supports data transfer rates of up to 3M baud. No external power supply is required as USB adapter takes its power from the USB bus.
  •  Feature
  •  Specification
  •  Download
  • Fully Compliant with USB Specification 1.1 / 2.0.
  • Allows up to 256 nodes on the bus.
  • Supports ±15kV HBM ESD Protected.
  • Supports data transfer rates up to 3M baud.
  • 512 byte receive buffer and 512 byte transmit buffer utilizing buffer smoothing technology to allow for high data throughput.
  • Supports remote wake-up and power-on-reset.
  • Compatible with Windows XP / Vista / 7 / 8 / 8.1 /10 / 11, Windows Server 2012 / 2012R2 / 2016 / 2019 / 2022 ; Mac OS 10.3 to 10.15 / 11 / 12; Linux OS 3.2 or higher.
